Specification

Hardware Parameter Q7DER
Working voltage 12V(3S)
Output voltage 5V (connect with PWM)
Dynamic current 900~1500mA @ 12V
Idle current 900mA @ 12V
Working environment temp. -20℃~+60℃
Output IP rtsp (1080p 30fps)
Local-storage SD card (Up to 128G,class 10, FAT32 or ex FAT format)
Photo storage format JPG(1920*1080)
Video storage format MP4  (1080P 25fps)
Control method TTL / S.BUS/ TCP
Gimbal Spec
Angle scope of structure design Pitch/Tilt: -60°~120°,    Yaw/Pan: ±360°*N
Angle scope of software design Pitch/Tilt: -45°~90°,   Yaw/Pan: ±360°*N
Vibration angle Pitch/Roll: ±0.02°, Yaw:±0.02°
One-key to center
EO Camera 1 Spec
Resolution 1920*1080 @60fps
Focus Length 7.2mm
Angle of View 42.28°*24.54°
EO Camera 2 Spec
Resolution 1920*1080 @60fps
Focus Length 25mm
Angle of View 12.71°*7.17°
IR Thermal Imager Spec
Angle of View 1 32°*25.8°
Angle of View 2 12.5°*10°
Working mode Uncooled VOx long wave (8μm~14μm) thermal imager
Detector pixel 640*512
Pixel size 12μm
Focusing method Athermal prime lens
Color palette White hot, pseudo color
Digital zoom 1x ~ 4x
Sync correct time Yes
EO Camera Object Tracking
Update rate of deviation pixel 60Hz
Minimum object contrast 5%
Minimum object size 16*16 pixel
Maximum object size 128*128 pixel
Tracking speed ±48 pixel/frame
Object memory time 100 frames
EO / IR Camera Object Tracking
N.W. 525g (with damping system)
Product meas. 95.9*86.7*135.6mm
Accessories 1pc gimbal camera device, screws, USB to TTL cable  / Hight quality plastic box with foam cushion
G.W. 525g
Package meas. 167*158*120mm



Hardware Parameter Q7DE
Working voltage 12V(3S)
Output voltage 5V (connect with PWM)
Dynamic current 600~1000mA @ 12V
Idle current 600mA @ 12V
Working environment temp. -20℃~+60℃
Output IP rtsp (1080p 30fps)
Local-storage SD card (Up to 128G,class 10, FAT32 or ex FAT format)
Photo storage format JPG(1920*1080)
Video storage format MP4  (1080P 25fps)
Control method TTL / S.BUS/ TCP
Gimbal Spec
Angle scope of structure design Pitch/Tilt: -60°~120°,    Yaw/Pan: ±360°*N
Angle scope of software design Pitch/Tilt: -45°~90°,   Yaw/Pan: ±360°*N
Vibration angle Pitch/Roll: ±0.02°, Yaw:±0.02°
One-key to center
EO Camera 1 Spec
Resolution 1920*1080 @60fps
Focus Length 7.2mm
Angle of View 42.28°*24.54°
EO Camera 2 Spec
Resolution 1920*1080 @60fps
Focus Length 25mm
Angle of View 12.71°*7.17°
EO Camera Object Tracking
Update rate of deviation pixel 60Hz
Minimum object contrast 5%
Minimum object size 16*16 pixel
Maximum object size 128*128 pixel
Tracking speed ±48 pixel/frame
Object memory time 100 frames
Packing Information
N.W. 230g (with damping system)
Product meas. 67.6*61.6*99.3mm
Accessories 1pc gimbal camera device, screws, USB to TTL cable  / Hight quality plastic box with foam cushion
G.W. 230g
Package meas. 167*158*120mm
