| Hardware Specs | ||||||||||
| Connector: | RJ-45(Ethernet) | |||||||||
| Mini HDMI | ||||||||||
| RP-SMA Female for antenna (Sky terminal) | ||||||||||
| Ground terminal - Female DB9*1(RS232 Serial), 3Pin Dupont*1(TTL serial) Sky terminal - 3Pin Dupont*2(TTL serial) |
||||||||||
| Antenna | Ground terminal: omni antenna + directive antenna (Gain: 12dBi) | |||||||||
| Sky terminal: omni antenna | ||||||||||
| Parameters | ||||||||||
| Frequency | 2.304-2.364GHz | |||||||||
| Thoughput | Up to 12 Mbps | |||||||||
| Modulation | TDD-OFDM with BPSK, QPSK, 16 QAM, 64 QAM; DBPSK, DQPSK, CCK | |||||||||
| RF Bandwidth | 2/ 4/ 8MHz selectable | |||||||||
| Error Detection | 1/ 2,1/ 3,1/ 4 32 bits of CRC, ARQ | |||||||||
| Encryption | 128 bit AES*, TKIP, WEP | |||||||||
| Sensitivity | -90dBm @ 12 Mbps，-95dBm @ 6 Mbps | |||||||||
| Communication range | 10~50 kilometers above, open without shelter | |||||||||
| Serial Bund Rate | 300bps to 921kbps | |||||||||
| Ethernet | 10/100 BaseT, Auto - MDI/X IEEE 802.3 | |||||||||
| Network Standard | 802.11a, 802.11b, 802.11g | |||||||||
| Networking Protocol | TCP,UDP,TCP/IP,TFTP,ARP,ICMP,DHCP,HTTP,SNMP,FTP,DNS,Se-rial,over IP,QoS | |||||||||
| Firewall | Port Forwarding, Access Control, IP List, MAC list | |||||||||
| Operating Modes | Point-to-Point, Point-to-Multipoint, Store & Forward Repeater, Peer-to-Peer | |||||||||
| Management | Local Serial Port Console,Telnet,We-bUI,SNMP,FTP & Wireless Upgrade,RADIUS authentication, 802.1q VLAN tagging | |||||||||
| Diagnostics | Battery Voltage, Temperature, RSSI,and remote diagnostics | |||||||||
| Conditions | ||||||||||
| Input Voltage | 10-30 VDC | |||||||||
| Output power | Up to 1W (Adjustable), 5-25W (additional) | |||||||||
| Environmental temperature | -40℃ to +85℃ | |||||||||
| Environmental humidity | 5-95%, non-condensing | |||||||||
| Package | ||||||||||
| Size | 78mm x 57mm x 30mm (Sky terminal) | |||||||||
| N.W. | Approx. 180g (Sky terninal with antenna) | |||||||||
| Accessaries | Ground terminal, sky terminal, HDMI converter*2, omni antenna*2, directive antenna, RS232 to USB cable and other hardwards | |||||||||
| Package Size | 360*300*250mm | |||||||||
| G.W. | 1650g | |||||||||
